YGDH04A -Upgraded Electric hydraulic Operation table

YGDH04A-Upgraded Electric Hydraulic Operation table is a high-performance medical device driven by an electric hydraulic system. It has low noise and high load-bearing capacity and is suitable for various surgical departments, such as thoracic and abdominal surgery, neurosurgery, obstetrics and gynecology, urology, etc. The bed frame, side armrests, base, and column cover are all made of durable SUS304 stainless steel to ensure long-term stable operation. The bed surface is designed as a five-section independently adjustable structure, which supports X-ray fluoroscopy and is convenient for imaging examination. Equipped with a handheld controller and a cylindrical controller, it is easy to operate and has the functions of "one-button lateral reset" and "one-button forward and backward flexion/recurvature", which greatly improve the convenience of operation. The bed surface can be interchanged between the head and legs, which is convenient for use with C-arm equipment. The waist part is made of carbon fiber material and has a manual lifting function to reduce weight and improve comfort. The built-in electro-hydraulic brake system ensures the stability of the bed during surgery. The mattress uses multi-layer memory foam, which is anti-static, waterproof, and anti-fouling, reducing the risk of bedsores. The built-in battery supports 10 full-cycle adjustments to ensure use without power. The whole bed has a load-bearing capacity of 450kg, which can meet the needs of most patients.

Contact Us
  • YGDH04A -Upgraded Electric hydraulic Operation table
  • YGDH04A -Upgraded Electric hydraulic Operation table
  • YGDH04A -Upgraded Electric hydraulic Operation table
  • YGDH04A -Upgraded Electric hydraulic Operation table
  • YGDH04A -Upgraded Electric hydraulic Operation table
  • YGDH04A -Upgraded Electric hydraulic Operation table
PREV：YGDH04G Electric hydraulic surgical operating table
NEXT：YGDH04 Ultra-low Electric hydraulic operation table

Product Description


Electric hydraulic operating table

1.The operating table is driven by a hydraulic system, with low noise and large load-bearing capacity, which can meet the different operations of various departments such as thoracic and abdominal surgery, brain surgery, gynecology, urology, otolaryngology, orthopedics, etc.

2. The table frame, side rails, bottom cover and column cover are all made of SUS304 stainless steel.

3. The desktop is divided into five parts: head, back, waist, hip and leg parts; the material of the desktop can be X-rayed.

4. It is equipped with a handheld controller and a column panel controller, which will automatically lock without operation for 30 seconds.


Ultra-low operating table

5.It has a one-button horizontal reset function.

6. It has a one-button forward and reverse flexion/extension function.

7. The table can be moved to the direction of the head and leg boards, and it also has an interchange function between the head and leg boards, and the perspective space reaches 1500mm, which is better matched with the C-arm camera.

8. The waist lift is manual lift.


500mm height adjustment table

9. Electric hydraulic brake.
10. A multi-layer memory foam mattress effectively reduces the occurrence of bedsores. The mattress is anti-static, waterproof, anti-fouling and easy to clean.
11. Built-in battery, when the battery is fully charged, it can run continuously and uninterruptedly for no less than 80 minutes without AC power.
12. The static load of the whole machine is 450 kg.

Table length

 2100mm

Table width

 520mm

Table lifting

600-1030mm

Headboard upwards/downwards

 ≥60°/ ≥90°

Backboard upwards/downwards

 ≥80°/ ≥40°

Leg board upwards/downwards/ outreached

 ≥ 20°≥ 90°

Forward tilt/ Backward tilt

 ≥30°

Left and right tilt

 ≥20°

Waist bridge lifting

 ≥120mm

Maximum translation distance

 ≥350mm

Flex / Reflex

  100°/ 220°
Item Quantity
Anesthesia Protective Screen 1 piece
Shoulder Support 1 set
Armrest 1 set
Body Support 1 set
Leg Support 1 set
Mattress 1 set
Hand-held Operator 1 set
